3nm 180° Red, Double, Ice-class, black anodized
P/N: 300-114G2ST-PRO-I180
3nm 180° double red, black, PRO-series
Built-in De-icing function Horizontally mounted on 400-037 POM base (IP68) Cable direction side incl. HDPE base plate Quality cable glands
Number
300-114G2ST-PRO-I180
Light Color
Red
Dimensions metric
Ø92,5mm x 96,5mm
Certification
This Navigation Light is certified by DNV, the Declaration of conformity and the certificates can be found on www.lopolight.com under Support
Intensity
>15cd
Dimensions imperial
Ø3.6" x 3.8"
Approved to
COLREG72,EN14744,IEC 60945,IACS E10,USCG,ABS,M.E.D.,DNV,LR
Visibility
3nm
Operating temperature
-60°C to 55°C
Operating Voltage
20-32VDC
EAN
5704438020276
IP rating
IP68
UPC Code
879343020408
Connection
Plug connector
Current consumption (mA @ 12VDC)
210
Current consumption (mA @ 24VDC)
100
Vessel size
Over 50M
Weight (Kg)
1.51 Kg
Weight (Oz)
53.26 Oz
